SCB-6995
2x DDR4 (ECC) SO-DIMM memory, up to 2400 MHz
Support Intel QAT (by SKU)
6x 1GbE RJ45 ports, 2x 10GbE SFP+ ports
1x M.2 B-Key, 1x mPCIe
1x mSATA, 1x eMMC
The SCB-6995A is a desktop networking system. It supports Intel Atom C3000 series CPU with QAT (encryption & decryption accelerator) for secure internet connection.
The SCB-6995A support 6 x RJ45 GbE and 2 x 10G SFP+ ports. The SCB-6995A has 1 x mPCIe and 1 x M.2 slot for future expansion, e.g. WiFi/LTE/5G module.
The SCB-6995A can connect with SATA/mSATA/eMMC storage. Customers can select suitable solution to meet their application.
1x M.2 (B-key for LTE/5Gmodule)
2x 10GbE SFP+ ports
1x HDD LED
1 x M.2 LED
1 x mPCIe LED
2 pairs LEDs for SFP+
6 pairs LEDs for 6 Ethernet ports Active/Link
status (Green)
non-condensing
SCB-6999
Desktop system with intel ATOM C3000 processor, 2x DDR4 SO-DIMM slots, 4x 2.5Gb ports, 2x 10G SFP+ port, M.2 & mCPIe slots for 4G/5G/WIFI expansion
SCB-6915
Desktop Network System with Intel Alder Lake-N or Amston Lake-C processor, 1 x DDR4 SO-DIMM, 6x 1G RJ45 ports (optional 1x 2.5GbE port or 1x 1GbE SFP port), 1 x DDR4 SO-DIMM, 1x 2.5”, 1 x mSATA, 1x eMMC, 2 x USB 3.0, 1x M.2
SCB-6913
Fanless Intel Atom (Elkhart lake) x6425E 4 Core SOC, 12W, 1x DDR4 SODIMM, 6x RJ45, 1x Console + USB2.0 , 2xM.2 for 4G/5G LTE, 1x M.2 for WIFI 6, 1x eMMC 16GB , 4x Micro SIM Slot, 1x HDMI
SCB-6997
Desktop Network Appliances, Intel® Celereon®/pentium®/Atom® (Apollo Lake) Network System, Six Copper GbE, eMMC, mSATA, SATA, mini-PCIe, Gen3 Bypass
SCB-6990
Intel® Atom C3000 (Denverton-NS) fanless system for SD-WAN Network Appliance, 2 x DDR4 SO-DIMM up to 32GB, 6 x RJ45 GbE, 2 x SFP, 2 x M.2 B key for LTE/5G module with 4x SIM cards, and mPCIe for WiFi module
SCB-6989
Desktop Network Appliances, Intel® Atom C3000 (Denverton-NS) Processor Network System, 8x Copper GbE, DDR4, mSATA, eMMC, mini-PCIe, PCIe, Bypass
SCB-6988
Desktop Network Appliances, Intel® Celereon®/pentium®/Atom® (Apollo Lake) Network System, Six Copper GbE, eMMC, mSATA, SATA, mini-PCIe, Gen3 Bypass
SCB-6914
Fanless Desktop Network appliance with Intel Pentium/Celeron/Atom Processor (Apollo Lake) Processors,4x 1GbE ports,1x 1GbE SFP, DDR3L SO-DIMM memory, up to 1600 MHz, 32GB eMMC, 2x USB 3.0, mini-PCIe for WiFi / LTE, 1x SIM
