AEWIN Mainstream Network Appliance, SCB-1742, Supports AMD Latest AM5 Ryzen 9000 and EPYC 4005 Processors
AEWIN is glad to announce that the 1U Mainstream Network Appliance, SCB-1742, now supports the latest AMD AM5 Ryzen 9000 and EPYC 4005 processors in addition to the original AMD Ryzen 7000 CPUs. Embedded with the AMD AM5 socket, the SCB-1742 is compatible with Ryzen 9000 and EPYC 4005 CPUs with the same BIOS which offer great flexibility and significantly reduce firmware efforts. Along with 2 channels of DDR5 up to 5600 MT/s (2 DIMMs per channel) and rich I/O supports, the SCB-1742 features great expandability, sufficient computing power, and low-latency communicating ability.
AMD AM5 Ryzen 9000 and EPYC 4005 processors are built using TSMC’s 4nm manufacturing process which provides excellent power efficiency and better performance-per-watt compared to Ryzen 7000 CPUs. The two CPU series share similar specifications, while AMD Ryzen 9000 processors feature built-in graphics and EPYC 4005 processors feature AMD infinite guard. With advanced CPUs, the SCB-1742 offers outstanding performance per watt with better efficiency. Benefited from the large core-count of high-performance CPU cores, the SCB-1742 is perfect for compute intensive applications including data/traffic analytics, timely threat detections, virtualization, and more.
Equipped with 10x on-board LAN ports including 4x 2.5GbE RJ45 ports with 2 pairs Gen3 bypass, 4x 1GbE RJ45 ports, and 2x SFP or 2x 1GbE RJ45 ports, SCB-1742 is ideal for a wide variety of network applications. There are 2x PCIe 4.0 x8 slots for AEWIN self-design NICs with wide range of 1-100G copper/fiber interfaces with/without bypass function or other accelerators. In addition, there is one optional PCIe x8 slot with PCIe x4 signal at the rear side for further expansion.
For long lifecycle support, AMD EPYC Embedded 4005 and Ryzen Embedded 9000 Processors provide 7-year planned manufacturing longevity. Apart from the options of CPU, the SCB-1742 is flexible for tailored configuration with its two expansion slots at the front side. It also provides alternatives to change the 2x front panel PCIe slots to 1x PCIe x16 slot for installing off-the-shelf add-on card for additional functions required. The SCB-1742 has great scalability while it does not compromise with its compact size. It is designed with 450mm short depth for easy deployment at a variety of locations.
The SCB-1742 has redundant PSU for outstanding reliability. To ensure security, it is with TPM2.0 to protect its start-up process and ensure the integrity of the hardware. With high throughput NICs installed, the system is perfect for the diverse network solutions like NGFW/UTM, DPI/IPS/IDS, DDoS protection, uCPE, etc. It can also serve basic network storage applications as it contains multi-storage medias including 2x hot-swappable SATA 2.5” HDD/SDD bays (4x SATA connector available for high-capacity support) and 1x M.2 2280 slot (M Key) for high-speed NVMe SSD.
Learn more about AEWIN SCB-1742 by visiting our product page below:
