Home Product Network Expansion Module NIC NFQ201
  • DSC09598
DSC09598
Network Expansion Module

NFQ201

Features
1x Intel® XL710-BM2
2x 40GbE QSFP+ Ports
Support VMDq, SR-IOV, DDP, DPDK
1 pair fiber bypass
Add to Compare Add to Inquiry
Download

AEWIN NFQ201AL/NFQ201BL Network Expansion Module is built upon the Intel® XL710 chipset, featuring 2x 40GbE QSFP+ ports and one pair bypass. SR-IO V functionality is enabled to offer DMA access for virtual machines, as well as DPDK enabled drivers for enhanced packet forwarding performance.

Platform
Form Factor
AEWIN Expansion Module
LAN Controller
1x Intel® XL710-BM2
LAN Switch
-
Features
VMDq, SR-IOV, DDP, DPDK
Ethernet Port
2x 40GbE QSFP+ Ports
Bypass
1 pair Bypass
Bus Type
PCIe Gen 3 x8
Mechanical
Dimension(W x D x H):74 x 194 x 29 mm
Weight(without tray): 210g
Environmental
Operating Environment
Temperature: 0-45°C(32-113°F)
Humidity: 20-90% RH
Storage Environment
Temperature: 0 -70°C(14-158°F)
Humidity: 5-95% RH @ 55°C
OS Support
Windows, Linux, FreeBSD
Order Information
NFQ201AL : 1x Intel XL710-BM2, 2x 40GbE QSFP+ Fiber w/ one pair multi-mode fiber bypass (150m), Port Sequence: Left to Right
NFQ201BL : 1x Intel XL710-BM2, 2x 40GbE QSFP+ Fiber w/ one pair single mode fiber bypass (10km), Port Sequence: Left to Right
