2U Rack-Mount Dual Intel® Ice Lake-SP Xeon® scalable series Processor and Intel® C621A PCH Network System, support DDR4 up to 2TB, 4 PCIe Gen4 x8 slot for expansion LAN module, 2x PCIe Gen4 x16 for Dual-width GPU Card, 2 x 2.5” SATA HDD swappable, IPMI, USB 3.0, 2 GbE, 1 Console, CF/mSATA/miniPCI-E, M.2, PCI-e, Redundant PSU
The SCB-1932 is a 2U Rack-Mount hardware networking system. Supporting Intel®Whitley/Ice Lake-SP with efficient performance processor Xeon® scalable series and Intel® C621A/C627A PCH (codenamed Lewisburg). The new generation platform provides highly performance, CPU cores up to 38 cores, 3 Ultra Path Interconnect (UPI) links up to 11.2 GT/s. The SCB-1932 supports 8x channels DDR4 register ECC RDIMM (up to 3200 MHz) and maximum memory capacity is up to 1TB with 64 PCI Express lanes per CPU, the SCB-1932 can support up to 8x Network Expansion Modules, support multiple different ethernet modules for flexible port configuration, such as 1/10/40/100 Gigabit fiber, Gigabit Copper/Fiber with or without BYPASS function. The maximum ethernet bandwidth capacity is up to 1,000GbE. The strong IO elements of SCB-1932 include two management port (one for management, another for option IPMI function), a console port, USB ports, LEDs for power/ HDD/ 2x GPIO. In addition, the SCB-1932 also supports two front hot-swappable 2.5” SATA HDDs/SSDs and onboard CompactFlash/m-SATA/miniPCI-E, M.2 slot for network storage application.
